010 / 087 / 089 / 090

010 / 087 / 089 / 090

010 - 3-speed gearbox introduced to the market in 1975. and installed in Volkswagen models with FWD drive (Cabriolet, Golf, Jetta) and Audi with engine capacity from 1.6L to 2.2L (80, 100, 200, etc.). In 1978, its modification was introduced to the market - 090, Vanagon.

010

Gears	Transmission Type	Drive	Torque (Nm)	Total ATF Capacity	ATF Replacement	ATF Type
3	AT	FWD	200	6.0L	3.0L	Dexron III

087 - 3-speed gearbox installed in Porsche 944 and 924. Other markings of this gearbox are: RH, RCA, RCD, RCE, RCB.

087

Gears	Transmission Type	Drive	Torque (Nm)	Total ATF Capacity	ATF Replacement	ATF Type
3	AT	FWD	225	6.0L	3.8L	Dexron III

089 - gearbox modification 010 introduced to the market in 1978. The problem with the controller seal was removed and the gear ratios were improved.

089

Gears	Transmission Type	Drive	Torque (Nm)	Total ATF Capacity	ATF Replacement	ATF Type
3	AT	FWD	240	6.0L	3.7L	Dexron III

090 - a modification of the 010 gearbox for RWD vehicles (Vanagon), introduced to the market in 1978. Ring gears of this rare modification are not used on any other Volkswagen models, but were used on several Audi models. A special differential was produced for the Vanagon.

090
