TG-81SC / AF50 / U880E / U881F / UA80F / AWF8F35 / GA8F22AW / AWF8F45

TG-81SC / AF50 / U880E / U881F / UA80F / AWF8F35 / GA8F22AW / AWF8F45

AWF8F35 / GA8F22AW / AWF8F45 / TG-81SC / AF50 / AF50-8 / UA80E / TG-80LS / U880E / UB80E / TG-81LS / EAT8 / U881F / UA80F / UB80F / U880F / AWF8F30

TG-81SC, U881E - The AWF8FXX series is the first series of 8-speed automatic transmissions compatible with cross-mounted engines. Developed by Aisin Warner engineers to occupy the same space as the TF-80SC, but increase the overall gear spread and reduce the spacing between gears. The AWF8F35 was released in 2015 and has become quite popular in BMW, GM, Volvo, Toyota and Lexus models. Differences between TG-81SC modifications include: torque, cooling system, friction discs and drums.


TG-81SC / U881E

Gears Transmission Type Drive Torque (Nm) Total ATF Capacity ATF Replacement ATF Type
8 AT FWD/AWD 350 6.6L 3.5L Toyota WS



AWF8F35, AF50-8, UA80E, TG-80LS U880E - Minor torque modification. It takes up little space and its torque reaches 480 Nm. Installed in European vehicles with a capacity from 2L to 3.5L.


AWF8F35 / AF50-8 / UA80E / TG-80LS / U880

Gears Transmission Type Drive Torque (Nm) Total ATF Capacity ATF Replacement ATF Type
8 AT FWD/AWD 350 6.6L Toyota WS


AWF8F45, UB80E, GA8F22AW, TG-81LS, EAT8 - Used as EAT8 by the Peugeot brand in cars after 2017. 4WD modifications: UA80F, UB80F, U880F.


AWF8F45 / UB80E / GA8F22AW / TG-81LS / EAT8

Gears Transmission Type Drive Torque (Nm) Total ATF Capacity ATF Replacement ATF Type
8 AT FWD/AWD 480 7.5L 3.8L Toyota WS

U881F, UA80F, UB80F, U880F, AWF8F30 - 8-speed gearbox designed for 4WD cars.
