AW60-40LE / AF13 / AW60-41SN / AF17 / AW60-42LE

AW60-40LE / AF13 / AW60-41SN / AF17 / AW60-42LE

AW60-40LE / AF13 / AW60-40SN / AF13-2 / AW60-41SN / AF17 / AW60-42LE

AW60-40LE, AF13 - 4-speed gearbox designed in 1995. by Aisin Warner for Suzuki, Opel, Daihatsu and Fiat FWD vehicles with engine capacity up to 1.6L. After testing on Suzuki Estima, it was used in models of various brands. According to GM classification, the AW60-40LE has the designation AF13.

AW60-40LE / AF13

Gears Transmission Type Drive Torque (Nm) Total ATF Capacity ATF Replacement ATF Type
4 AT FWD 180 7.5L 3.5L Type T-IV



AW60-40SN, AF13-2 - A lightweight copy of the AW60-4LE produced since 2002.

AW60-40SN / AF13-2

Gears Transmission Type Drive Torque (Nm) Total ATF Capacity ATF Replacement ATF Type
4 AT FWD 170 7.3L 3.5L Toyota ATF WS


AW60-41SN, AF17 - In 1998, 4-speed gearboxes were produced. For FWD Suzuki, Opel and Chevrolet cars with engine capacity up to 1.8L. Applies to GM classification - AF17.

AW60-41SN / AF17

Gears Transmission Type Drive Torque (Nm) Total ATF Capacity ATF Replacement ATF Type
4 AT FWD 160 7.2L 3.6L Type T-IV


AW60-42LE - 4-speed gearbox produced from 1998 to 2011. Used in GM and Suzuki vehicles. Structurally similar to AW60-41SN.

AW60-42LE

Gears Transmission Type Drive Torque (Nm) Total ATF Capacity  ATF Replacement ATF Type
4 AT FWD 180 7.6L 3.8L Type T-IV
